Insulated door and window system
THERMO 60WD
Glazing of all types in an elegant system. Folding walls, windows and doors are available in bespoke sizes.
The universal, thermally broken folding door and glazing system glides smoothly thanks to high quality rollers.
The folding door is suitable for widths of up to 1.0 m and a glazed unit thickness of up to 32 mm. Individual colour and design ensures that your individual desire is fulfilled; the folding doors can be folded to the left or right or both sides; equally they can be opened inwards or outwards. The first element can be used as a door, accessible and lockable from both sides. Windows and fixed glazing can be combined as required with this system.
– Stable systems, opening windows and doors can be combined as required. Thermo 60WD system meets your requirements with single and double panel doors.
– Nox internal-external handle.
– Various combinations and multiple design options are possible.
– The simplistic appearance of the folding door systems is achieved with hidden fittings during assembly.
Technical Details
Max 1000 mm
Max 2700 mm
Max 75 Kg
60 mm
Insulation
Uf 1.8 W/m².K
Tempered, laminated or Solar Low-e double glazing up to 42mm thickness or triple glazing can be used.
Panels can be opened inwards or outwards
Can be folded to the right, the left or folded in either direction
Can be opened from middle to the both sides
Panel storage areas can be on both the left and the right with panels moving to both sides.
Certified Quality
Accredited certificates prove the quality and expertise behind the systems and services by Sunparadise.
• Quality management in accordance with ISO 9001
• In-house production control in accordance with DIN EN 1090
• Environmental management in accordance with ISO 14001
• Certified sound insulation and wind resistance categories
• Burglar resistance in line with RC3
• CE label in line with E.U. requirements
Získejte podrobné informace o našich produktech
Ať už se jedná o návrh nebo obecnou podporu, náš tým odborníků se těší na vaši podporu.
F.A.Q
The Thermo 60WD is an insulated door and window system that offers a universal and thermally broken folding door and glazing solution.
It is designed for folding walls, windows, and doors in bespoke sizes.
The Thermo 60WD system features high-quality rollers that ensure smooth gliding of the folding doors.
It can accommodate widths of up to 1.0 m and glazed unit thicknesses of up to 32 mm.
The folding doors can be folded to the left, right, or both sides, and they can also be opened inwards or outwards.
The first element of the folding door system can be used as a door, accessible and lockable from both sides.
The system allows for the combination of windows, fixed glazing, and other opening elements as required.
Yes, the Thermo 60WD system offers individual color and design options to fulfill specific desires and requirements.
The system allows for various combinations and multiple design options to suit the desired aesthetic.
The Thermo 60WD system achieves a simplistic appearance by using hidden fittings during assembly.
This ensures a clean and aesthetically pleasing look without visible hardware.
The system features the Nox internal-external handle, providing a stylish and functional option for operating the folding doors.
Yes, the Thermo 60WD system can accommodate both single and double panel doors, meeting various requirements.
The maximum panel width specified for the Thermo 60WD system is 1000 mm.
For more detailed information or if you have any specific questions, we recommend contacting our sales expert who can provide further assistance.
